Maximize Drawer Box Height for Generated Drawers
Update date2026-07-13

Setting Path: AiHouse Admin Backend -> Resource Configuration -> Default Material Configuration -> Feature Switches

After this feature is enabled, for vertical drawers created with the Generate Drawer feature, the overlay values around the middle drawer front, as well as the corresponding overlay values of the top and bottom drawer fronts, are set to No Overlay (0). This maximizes drawer height and makes the drawer box height more reasonable.

In the illustration below, the cabinet on the left shows the result with height maximization enabled: the middle drawer is taller than the top and bottom drawers. On the right, with height maximization disabled, every drawer has the same height.
